Installing Mac OS X Lion on a Clevo M860TU




Known issues
  • Wifi doesn't work, and no driver is available. Use a USB adapter or cable
  • If your sound doesn't work, reinstall AppleHDA.kext from the kit using Kext Helper

Prerequisites
  • A Mac/Hackintosh with (Snow) Leopard (doesn't have to be the computer you want to install Lion to)
  • A USB drive of at least 5GB (and no data)
  • A Lion app or dmg
  • A USB mouse

Preparing your BIOS
First of all, you'll have to make sure your BIOS version supports AHCI for SATA. If it doesn't, you'll have to flash it. This thread may help you, but then you're on your own, sorry.


Preparing the installation disk
  1. Download Kakewalk for Lion, unzip it and launch the Kakewalk app
  2. Choose "Install to USB" and select your Lion app or dmg
  3. Kakewalk will then ask you for your motherboard version. Just keep the first one and finish the install
  4. Download and extract my Lion M860TU kit: GTX 260M (with nvEnabler) - 9800GTS
  5. Open a terminal and run prepare_disk.sh from the kit by typing:
    cd Downloads/Lion_M860TU/
    sh prepare_usb.sh
    Replace the directory by the one you extracted the kit to

Installing Lion
  1. Backup all your data
    I recommend using Time Machine so you can restore easily on your new Lion
  2. Reboot, and make sure to boot on your USB drive (press F1 during boot to choose the startup disk).
  3. Choose your USB drive from the menu (called Kakewalk).
    If you get a Kernel panic here (dark screen with reboot message), power off and start again but type "-x" before pressing enter to choose your disk.
    If you get stuck on the Apple logo and nothing else (no spinner, no disk activity) for a few minutes; just power off the computer and start again.
  4. Plug in your USB mouse as your touchpad won't work, follow the installation instruction
  5. Once the installation is complete, reboot back to the setup (Kakewalk disk again, just like you were doing a new install in steps 2 and 3)
  6. Choose your language, then open a terminal from the Utilities menu, and run
    sh /post_install.sh LIONVOL
    (replace LIONVOL by the name of the volume you installed Lion to, case-sensitive)
  7. Reboot from your USB drive again, but this time choose the volume with Lion installed
  8. Setup your account
    If you restore a Time Machine backup from another Hackintosh, choose what you restore wisely! I had to start over 3 times because of a kext causing a kernel panic...

Installing the bootloader
  1. Once you're in Lion, run Kakewalk from your USB disk, but this time chose "Install to computer". Again, leave the first motherboard selected
  2. Open a terminal and run prepare_boot.sh from the kit by typing:
    cd /Volumes/Kakewalk/
    sh prepare_boot.sh
  3. Eject the USB drive and reboot, your new Lion install should boot automatically

Upgrading to 10.7.1
  • If you installed 10.7.0, you can simply upgrade using Software Update
  • This guide should work to install 10.7.1 directly, but I didn't test it myself

    Please write a comment below if you need any help, or let me know if everything worked!
